The Twin Vee 340 center Console GFX has Arrived!

For over 27 years, Twin Vee has been designing and building the “Best Riding Boats on the Water™”, Twin Vee’s newest PowerCat is our 340 GFX. Twin Vee’s all-new 34-foot PowerCat is the next-level platform for your offshore adventures.

The Twin Vee 340 Go Fish-X is designed for the avid fisher and boater who lives life with a forward motion, power, and performance attitude. Twin Vee’s 340 GFX is on-point, no fish will escape the boundless reach of our 340 GF X. Standard equipment includes 382 gallons of fuel capacity, 800 Maximum HP, 300-gallon fish boxes, three live wells – two in the stern and one in the helm seat, XXL coffin box, Llebroc seating and much more. Inject Twin Vee DNA, and you have a wave-eating, fish-catching beast of a nautical machine that will satisfy your passion and desire to compete as a World Class sportsman.

Twin Vee engineered the new 34-foot PowerCat GFX to merge the highest quality elements of fishing on a center console with the ride stability of twin hulls to deliver a vessel worthy of anglers everywhere. Our mission never waivers…..design and build next-level performance with stability and comfort for offshore boating and fishing.

Mission Accomplished!

FrameGrabSequence00_05_58_23Still018
FrameGrabSequence00_05_43_26Still019
FrameGrabSequence00_07_11_46Still016
FrameGrabSequence00_06_12_35Still021
FrameGrabSequence00_05_10_48Still012
previous arrow
next arrow

3D Interactive Walkthrough

Helm Station

Forward Chaise Lounge Seating

Bow Seating and Storage

G.G. Schmidt Aft Seating

Premium Helm Seating

Mezzanine Seating

Lewmar Stainlesss V1XL Winch
Lewmar Stainlesss V1XL Winch
Upholstered Bow Seating Bench
Upholstered Bow Seating Bench
Pass-through Transom with Drop Board
Pass-through Transom with Drop Board
Under Gunnel Rod Storage
Under Gunnel Rod Storage
T-top with integrated E-Box
T-top with integrated E-Box
Stainless Bow Roller
Richie Voyager Compass
Rear Facing Mezzanine Seating
Rear Facing Mezzanine Seating
Premium Helm Seating with Custom Stitched Upholstery
Premium Helm Seating with Custom Stitched Upholstery
Motorized Anchor Light
Motorized Anchor Light
Macerated Fish Box
Macerated Fish Box
Livewell
Livewell
Aft Tackle Center and Storage
Aft Tackle Center and Storage
Port and Starboard Helm Seating Storage
Port & Starboard Helm Seating Storage
GG Schidmt aft seating
GG Schidmt aft seating
Forward Lightbar
Forward Lightbar
Battery Charger Port
Battery Charger Port
Custom Switch Panel
Custom Switch Panel
Console Dry Box with USB
Console Dry Box with USB
Chaise Lounge Seating with Insulated Cooler or Fishbox
Chaise Lounge Seating with Insulated Cooler or Fishbox
Bow to stern bolsters
Bow to stern bolsters
Aluminum Dive Ladder
Aluminum Dive Ladder
previous arrow
next arrow

340 GFX Specs

LOA

34′ 0″

BEAM

11′ 4″

DRAFT

20″

FUEL CAPACITY

382 Gallons

MAX POWER

800 HP


LIVEWELL CAPACITY

2X45 Gallons

COG from Bow

211″

DRY WEIGHT w/ Engines

11,300 lbs

*Due to mandatory EPA regulations in fuel systems, usable fuel capacity is an estimation and may not reflect actual capacity

340 GFX Standards

Hull and Deck

  • 8” Stainless Steel Pull-up Cleats – (7)
  • Advanced cored fiberglass construction with composite/resin stringer system
  • Aluminum 4-step dive ladder with handrails
  • Cup holders: Stainless Steel (6) (2)-Console, (2) per side gunwale
  • Drain covers: stainless steel w/Twin Vee Logo
  • Fresh water tank w/ washdown (13g tank)
  • Fuel Cells – 191 Gallon each x 2 w/Fuel Level Sensor
  • Gel Coat Color: White as standard
  • Grip Tek – yacht style non-skid
  • High-Quality EVA decking – covers the Bow floor, port/stbd Fish Box Lids and Anti-fatigue Helm Pad & Foam Fish Ruler
  • In-Deck fish boxes/storage Macerated, Port & Stbd
  • LED Courtesy lights throughout, Blue
  • Lewmar Stainless V1XL GO 500w Windlass with 1400 lbs. pulling power
  • Rod holders: (16) Stainless Steel – 8 per side gunwale & (6) on Aluminum T-Top connect piece
  • Rod Holders: Aluminum transom mounted “Euro” rod holders 10 total (5) each port/stbd
  • Rod Storage, Under Gunwale, Thermoformed & Flush Mounted
  • Rub Rail: Thick Flexible rub rail with insert, white or black
  • Outboard Brackets
  • Stainless Steel Bow and Stern Tow Eyes – (3)
  • Stainless Steel Bow Roller
  • Tension hinges: Stainless and Brass
  • Thru hulls: Stainless Steel
  • Transom Walkthrough with drop board to Swim/Fish/Sun platform
  • Twin Vee logos, Model Designator logo
  • Upper Bow Storage with Molded Fiberglass Hatches
  • Wash down: Raw water washdown, stern

Console, Helm & T-Top Features

  • 3 Spoke Polished Stainless Steering Wheel w/ Turning Knob
  • 3 Bank battery charger
  • ABYC Standard Fire extinguisher
  • Acrylic Dash Panel w/ extra-large surface area for electronics
  • Acrylic Windshield – 3 Sided
  • Battery selector with on/off switches (2)
  • Center Sport Console with forward facing insulated coffin/storage box, fully upholstered lounge style seating
  • Electric Marine Horn
  • Marine head, self-contained
  • Seastar Electric/Hydraulic Steering
  • Ritchie Voyager Compass
  • Stainless Steel Cup Holders (2)
  • Switch panel: Gloss Black Panel push buttons [blue LED lights/red in use], USB and 12v receptacle with circuit breaker protection
  • Thermoformed & Flush Mounted Footrest (Black)
  • White Powder Coated Aluminum Door

T-top Features

  • Electric motorized anchor light/electric antenna mount
  • Flood/Search Light Bar LED, forward & aft, 10,000+ lumens- independently switched
  • Integrated Anodized Aluminum T-top system, flush mounted onto console
  • LED Courtesy lights throughout, Blue
  • Molded Fiberglass hardtop w/ integrated E-box, acrylic door, recessed overhead LED lights and Outrigger pads
  • Navigation lights, port & stbd

Livewells, Pumps & Storage

  • 2000 GPH Bilge pumps with float switches (4)
  • Coffin insulated storage/fish box – forward facing/upholstered
  • Freshwater tank w/washdown (30gal)
  • Hooker Livewell System w/ (3) 2000gph pumps [2 main + 1 backup]
  • In-Deck Storage, Fiberglass Hatches, Diaphragm Pumps, Port & Stbd
  • Molded Fiberglass Bilge access hatches
  • Raw Water Washdown Pump
  • Stern 3-drawer tackle centers, 2 total (1 ea.) port & stbd
  • Twin transom live wells (45gal), (1 ea.) port & stbd

Seating and Upholstery

  • Bow Storage, Insulated and Dry, with Hatches, Friction Hinges
  • Bow Upholstered Bench Cushion w/ Backing
  • Chaise Lounge seating upholstered/contoured
  • Fiberglass Molded helm seat w/ footrests, aft facing triple helm seats with bolsters
  • Premium helm seating w/ arm rests upholstered with marine grade material

340 GFX Options

Available Options

  • Aluminum Powder Coat Gloss/Textured (White or Black)
  • Aluminum Trolling Motor bracket mounted on bow
  • Fusion Basic or Premium marine grade stereo systems
  • Gel Coat Colors: Ice Blue, Seafoam or Whisper Gray
  • Single or Dual 16” Garmin Displays w/ transducer
  • Premium GG Schmitt aft seating w/ polished stainless-steel port/stbd

340 GFX Power Options

Twin Suzuki 350ATXX

Engine Type
DOHC 24-Valve

Displacement
267.9 (4390)

Max HP
350

Starting System
Electric

No. of Cylinders
V6 (55°)

Operating Range (RPM)
5700-6300

Weight
X 727lbs, XX 747 lbs

Alternator
12V 54A

Color Options
Black

Twin Suzuki 350ATXX

Engine Type
DOHC 24-Valve

Displacement
267.9 (4390)

Max HP
350

Starting System
Electric

No. of Cylinders
V6 (55°)

Operating Range (RPM)
5700-6300

Weight
X 727lbs, XX 747 lbs

Alternator
12V 54A

Color Options
White
